Foam Water Pressure Fire Rubber Hose Manufacturers

Fire Hose pipe Foam Water Pressure Rubber HIC Universal

Foam Water Pressure Fire Rubber hose manufactured in blended Nitrile and SBR synthetic rubber tube double textile braided of high tenacity dipped nylon yarn with good adhesion used as fire hose for transfer of fire retardant with water at high pressures for fire-fighting equipment application as per ASTM D 412 specifications produced by HIC Universal India exporters of fire engine hoses to UAE, Saudi Arabia, Venezuela, Algeria, South Korea, USA, Iraq, England UK, Oman, Bahrain, Yemen, Russia, Iran, China, Indonesia, Singapore, Nigeria, EU, Qatar.

Fire Water Foam Hose TECHNICAL SPECIFICATIONS: MADE IN INDIA * HIC

ID = NB size range (mm)Working Pressure (bar)Rubber Tube (lining)Cover & FinishReinforcementBurst Pressure (bar) & Temperature
19, 25, 32, 38, 50

Till 2”
17
(=240 psi)

Test Pressure 1.5 : 1

Synthetic NBR (nitrile) & SBR blended, water & foam resistant
Lining Av. T.S.: 8300 kPa
Av. Elongation: 400%
Natural & Synthetic Neoprene blended, heat resistant rubber & UV sunlight protected; Wrapped
BLACK color
Synthetic double braided nylon yarn 51

- 35ºC to + 90ºC

Safety Factor
3 : 1

* Roll Lengths manufactured are 15.25 meters Min. (= 50 feet Approx.) and 30 m Max up to 1-1/2inch Inner Diameter size hose. Above 38mm (=1-1/2”) NB, Max. Length produced is 20 meters.

** Packaging in coils straight stuffed from factory into direct truck/ trailer.

***Crimped Couplingssuch as quick couplings Male Female also supplied.
